Flagship Full function SYNC Clock mode DAC KITs

Note:

1. RaspberryPi and the USB interface are not included. But user can install them at any time by just simply plugging-in. Amanero Combo384 is highly recommended.
2. The Apple remote controller is not include.
3. Under this configuration, DAC works in SYNC mode, so the MCLK cable must be connected from FifoPi to them.
4. Need 3.3V,5V and +/-5V to work. Power supplies are sold separately not be included in this KIT.

#92A Flagship Full function SYNC Clock mode ES9038Q2M Dual Mono II DAC

1. #1D FifoPi Q7II
2. #4B ES9038Q2M Dual Mono II DAC
3. #6B OPA861 Zero feedback balanced I/V
4. #19D ReceiverPi DDC
5. #35C StationPi SMT
6. #49B MonitorPi Pro
7. #50A GPIO extension KIT4.
8. #50B GPIP spacer
9. 2x#12A 13/2.5mm standoffs

#92B Flagship Full function SYNC Clock mode ES9038Q2M Dual Mono II DAC  assembled and tested

Same as #92A but fully assembled and tested. MonitorPiPro was also setup properly for the best optimized performance. Just plug and play by applying 5V,+/-5V and  and 3.3V power supplies.

Power supply recommendations

3.3V: UcPure 3.3V is high recommended for this project. Because of the ultra-low ESR of UcPure, this 3.3V can be shared by the Q7 clean side and the DAC.

5V: UcPure 5V is high recommended for this project if the RPi is not installed local.  Otherwise, a LinearPi 5V and a UcConditioner 5V will be good to go.

High quality 3.3V+5V power supply solutions are here.

+/-5V: Two UcPure 5V would be high recommended for DAC for the best possible sound quality.  Otherwise,  LinearPi 5V dual with two UcConditioner 5V will be good alternative.

Possible upgrade

#80A/#80B or #80C/#80D SC-Pure clocks
